The clean air filtered through the HEPA filter forms the vertical airflow from the ceiling to the bottom area, and maintains the work space as positive pressure (+) with class 100 cleanliness.
Dimension
standard Exterior W / mm D / mm H / mm
1340 742 1231
Interior W / mm D / mm H / mm
1219 617 585
Color Gray
Door Laminated glass
Control panel LCD digital display panel
Material
Exterior Steel plate cold commerica / Aluminium
Interior Stainless steel 304
Support stand Carbon steel pipes for ordinary piping
Performance
Certification CE
Avg. downflow velocity (m/s) 0.3~0.4 (variable set speed)
Filter efficeincy HEPA filter (>99.99% at 0.3㎛) / Class 100
Pre-Filter Nylon filter
Noise level (db) ≤65db(A)
Safety alarm system X
Electrical
Power supply 220V, 50/60Hz (110V is available)
FL lamp 36W x 1EA
UV lamp 20W x 1EA
Power Receptacle 1EA
Valve
Utility Valve 1EA (vacuum)
Option
1EA
Utility valve (gas, air, water)
Utility hole
Support stand / frame (height) – 633mm
Leveling caster (height) – 71mm
Etc
Differential pressure gauge 1EA
