Features :
* Waterproof(IP66) housing, Backlit custom LCD display
* Fast, accurate and easy to use, RS 232C communication
* Automatic pH buffer Recognition
* Two-way R232C Communications
* Ion Concentration Measurement in mg/L
* Automatic Temperature Compensation (ATC)
* Internal Diagnosis for normal Operation Check
* Precise Measurement with Cell constant Designation
* Using high sensitive polarographic type DO sensor
* Automatic compensation for salinity and barometric pressure
* Most recent Calibration Data use for direct Measurement
* Automatic/manual Calibration for simple and convenient Use
* Automatic Power-off for saving Battery
* Low Battery Alarm
* Data-log up to 100 Points, Auto power-off
* Certificate CE mark, GD mark, ISO 900
Specifications :
| pH | Range Resolution Relative Accuracy |
-2.000~19.999 0.001/0.01/0.1 ±0.002 |
| Concentration | Range Resolution Relative Accuracy |
0.0001~19999mg/L ± one least significant ±0.25% of Reading |
| Millivolts | Range Resolution Relative Accuracy |
±1999.9 0.1 ±0.1mV |
| DO | Range Resolution Relative Accuracy |
0.00~19.99mg/L 0.01/0.1 ±0.5mg/L |
| O₂ | Range Resolution Relative Accuracy |
0.0~60.0％ 0.1% ±1 digit |
| Air Saturation | Range Resolution Relative Accuracy |
0.0~199.9％ 0.1% ±1 digit |
| Conductivity | Range Resolution Relative Accuracy |
0 to 199,999μS/cm 0.01/0.1 ±0.5% |
| TDS | Range Resolution Relative Accuracy |
0 to 1999mg/L 1 mg/L ±2％ |
| Salinity | Range Resolution Relative Accuracy |
0.0 to 80.0ppt 0.1 ±0.1 |
| Temperature | Range
Resolution |
pH/Ion/EC => 0~110℃ DO => 0~60℃ 0.1℃ ±0.4℃ |
| Temperature Compensation | Auto | |
| Calibration | pH => Auto/Manual(3Point) Ion. DO, EC => Auto |
|
| Datalog | 100 Points | |
| Print Capability | Yes | |
| Display | Graphic LCD | |
| Inputs | 8 Pin DIN Waterproof | |
| Outputs | RS232C (Computer/Printer) | |
| Power | Rechargeable Battery DC Power Adaptor |
|
| Certification | ISO9001, CE, GD mark | |
| Dimension | 220(L) x 80(W) x 40(H), Weight 0.45kg | |
| Waterproof | IP66 | |
Accessories :
(1) Standard
– Combination pH Electrode / ATC Probe
– Buffer Solution (pH 4.00, 7.00, 10.00) 125ml
– Instruction Manual
– Rechargeable Battery / AC/DC Adaptor
(2) Option
– Conductivity Cell / ATC Probe
– Conductivity Standard Solution 125ml
– DO Polarographic Electrode / ATC Probe
– DO Membrane Kit
– ORP Electrode
– Ion Selective Electrode
– pH Electrode Storage Solution
– pH Electrode Filling Solution
– Buffer Solution (pH 4.00, 7.00, 10.00) 125ml/475ml
– RS232C Interface Cable
– Exterior Thermal Printer
– Carrying Case
